Steam heat source
Drum type

Water and sludge treatment products

Sludge Dryer
K Series

This is a drum-type dryer that performs drying by a steam-heated drum. This machine can convert waste activated sludge and chemical sludge into dried sludge with a water content of 10 to 40%, reducing the amount of waste sludge. * The K series is a product of KANKYO SETSUBI Co., Ltd.

製品紹介画像
Brochure Download Consultation & Quotation

ADVANTAGES

Reduces significant amount of waste sludge

By drying the dewatered cake with a water content of about 80% to the water content of 10 to 40%, the dryer significantly reduces the amount of waste sludge. Your sludge disposal cost is greatly reduced.

Water content and weight of sludge

Sludge condition Water content Sludge cake weight
Raw sludge 99% 10000kg
Thickened sludge 96% 2500kg
Dewatered cake 83% 588kg
Dried sludge 40% 167kg
30% 143kg
20% 125kg
10% 111kg

*Trial calculation for solid content of 100 kg-DS

Compact design and easy installation

When combined with the VOLUTE™ Dewatering Press, the dewatered cake discharged from the dewatering machine is fed directly into the dryer which produces the dried cake continuously. Large-scale operating systems such as storage hoppers, large drying tanks, and motors are not required.
In addition, the unique double layered drum structure ensures sufficient drying area.
Its compact design makes it suitable for small facilities, and the installation is also easy.

VOLUTE™ Dewatering Press + K series Example
of combined layout

PROCESS FLOW

  1. 01

    Discharge of Dewatered Cake

    The dewatered cake with a water content of about 83% discharged from the sludge dewatering press is continuously fed into the dryer.
  2. 02

    Drying Drum

    The sludge is dropped onto the drum surface and then it gets dried during one rotation.
  3. 03

    Dried Cake

    Dried cake with a water content of 10 to 40% is discharged.
List of Case Studies

RENTAL

Rental of Sludge Dewatering Presses

You may wonder, “Can the machine dewater the sludge as desired?” or “Is it difficult to operate the machine?”
In addition to eliminating concerns before purchase, you can also use our products as a replacement machine during the service period of an existing dewatering machine or during the construction period of a wastewater treatment facility.

Flow for Product Installation

流れ
Feel free to contact us. After collecting information about your treatment process, sludge volume, operating hours, and other conditions, we will select the most suitable model for your sludge and your concerns. During jar test, we will simulate the amount of chemicals to be dosed, the estimated water content of the dewatered cake, etc. Upon request, a pilot test can be performed (for a fee). After determining the specifications and ancillary equipment, we will start producing the equipment. Our sales representative or service engineer will perform operational adjustments at your wastewater treatment plant and you will check how to operate the system before we hand over the equipment.
