Specifications List

To inquiry form

Sludge Dewatering Press

GS series

Raw Wastewater /
Waste Activated Sludge /
Chemically Precipitated Sludge		 Dissolved-air
Flotation Sludge
Sludge
Concentration
(TS)		 0.2% 1.0% 2.0%
GS-101 up to 3kg‐DS/h
(up to 1.5m3/h )		 up to 4.5kg‐DS/h
(up to 0.45m3/h )		 up to 7.5kg‐DS/h
(up to 0.37m3/h )
GS-131 up to 6kg‐DS/h
(up to 3.0m3/h )		 up to 9kg‐DS/h
(up to 0.9m3/h )		 up to 15kg‐DS/h
(up to 0.75m3/h )
GS-132 up to 12kg‐DS/h
(up to 6.0m3/h )		 up to 18kg‐DS/h
(up to 1.8m3/h )		 up to 30kg‐DS/h
(up to 1.5m3/h )
GS-201 up to 13kg‐DS/h
(up to 6.5m3/h )		 up to 20kg‐DS/h
(up to 2.0m3/h )		 up to 33kg‐DS/h
(up to 1.67m3/h )
GS-202 up to 26kg‐DS/h
(up to 13.0m3/h )		 up to 40kg‐DS/h
(up to 4.0m3/h )		 up to 66kg‐DS/h
(up to 3.3m3/h )
GS-301 up to 30kg‐DS/h
(up to 15.0m3/h )		 up to 45kg‐DS/h
(up to 4.5m3/h )		 up to 75kg‐DS/h
(up to 3.75m3/h )
GS-302 up to 60kg‐DS/h
(up to 30.0m3/h )		 up to 90kg‐DS/h
(up to 9.0m3/h )		 up to 150kg‐DS/h
(up to 7.5m3/h )
GS-351 up to 60kg‐DS/h
(up to 30.0m3/h )		 up to 90kg‐DS/h
(up to 9.0m3/h )		 up to 150kg‐DS/h
(up to 7.5m3/h )
GS-352 up to 120kg‐DS/h
(up to 60.0m3/h )		 up to 180kg‐DS/h
(up to 18.0m3/h )		 up to 300kg‐DS/h
(up to 15.0m3/h )
GS-401 up to 80kg‐DS/h
(up to 40.0m3/h )		 up to 120kg‐DS/h
(up to 12.0m3/h )		 up to 190kg‐DS/h
(up to 9.5m3/h )
GS-402 up to 160kg‐DS/h
(up to 80.0m3/h )		 up to 240kg‐DS/h
(up to 24.0m3/h )		 up to 380kg‐DS/h
(up to 19.0m3/h )
Model Dimensions (mm) Total Power
Consumption (kW)		 Weight (kg)
L W H Empty Operation
GS-101 2045 1236 1440 0.40 344 546
GS-131 2190 1236 1440 0.40 354 556
GS-132 2190 1236 1440 0.50 464 676
GS-201 2581 1236 1440 0.50 514 736
GS-202 3165 1465 1855 1.35 1260 1885
GS-301 3765 1415 1855 1.35 1240 1890
GS-302 3985 1700 1855 1.75 1775 2775
GS-351 4500 1665 2250 2.45 2135 3105
GS-352 5180 1910 2255 5.95 4100 6730
GS-401 5870 1905 2250 4.45 3200 5730
GS-402 6170 2305 2250 5.95 4830 8700

* Throughput above is calculated as approximate and may vary depending on sludge condition. For model selection, please contact us.
* Throughput of each model is based on sludge cake with 20±5% solids content.
* There is no certain upper limitation on inlet sludge concentration, however, the target sludge must be flowable.
* Throughput of DAF Sludge is based on sludge containing much fat, oil, and grease such as meat processing applications etc.
