Basic model
with simple structure & easy operation

Water and sludge treatment products

VOLUTE™ Dewatering Press
FS Series

In addition to a simple structure with basic VOLUTE™ features such as power-saving, water-saving, and low noise, this model has a control function (VAS: VOLUTE™ Antilock System) that supports the continuous stable operation. The machine prevents overload stoppage, which may reduce an hourly throughput. It is easy to operate having the same control system as higher-end models adopted.

製品紹介画像
360度 拡大表示
Brochure Download Consultation & Quotation

ADVANTAGES

  • No clogging even with oily sludge
    No clogging even with oily sludge
  • No pre-thickening required, TS: 0.2% or more
    No pre-thickening required, TS: 0.2% or more
  • Prevent overload stoppage that reduce an hourly throughput
    Prevent overload stoppage that reduce an hourly throughput
  • Applicable for various applications
    Applicable for various applications
  • High solid capture rate
    High solid capture rate
  • Water-saving & Power-saving
    Water-saving & Power-saving
  • Low noise and low vibration
    Low noise and low vibration
  • Easy operation and easy maintenance
    Easy operation and easy maintenance
  • Excellent expandability<br>Additional cylinder unit can be added even after delivery
    Excellent expandability
    Additional cylinder unit can be added even after delivery

Preventing overload stoppage that delays dewatering

Equipped with the stable operation support control VAS (VOLUTE™ Antilock system), this machine prevents overload stoppage, which may cause dewatering to stall.
Constantly monitoring the current value of the screw motor, this machine controls the screw speed properly to ensure stable dewatering.

No clogging even with oily sludge

The machine has a filter element that consists of alternating layers of rings fixed at four locations (fixed rings) and vertically movable rings (moving rings) maintaining a gap between them, and a single screw that is threaded through the filter element to transfer and compact the sludge.
A clog-free self-cleaning mechanism is achieved since the screw rotates at a constant speed in contact with the floating ring, driving the floating ring to clean the filter element gap. The machine delivers stable dewatering performance even with oily sludge.
The amount of cleaning water for preventing clogging is very small compared to other types of dewatering machines.

No pre-thickening required

This machine has an integrated structure in which two processes, thickening and dewatering, are handled by a single filter element, allowing the user to directly charge low-concentration sludge having a TS of about 0.2% without providing a thickening system in the preceding stage.
This not only reduces the construction and operating costs for the thickening and storage systems but also reduces odor because aerobic sludge is dewatered.
The machine can also efficiently capture phosphorus in waste activated sludge to the dewatered cake side, reducing the load caused by phosphorus returning to wastewater treatment.

Conventional sludge treatment process
Aeration tank direct dewatering

PROCESS FLOW

  1. 01

    Flow Control Tank

    Sludge feed is regulated with the overflow pipe, returning excess volume to the sludge storage tank.
  2. 02

    Flocculation Tank

    Polymer and sludge are stirred and mixed, forming flocs suitable for VOLUTE™.
  3. 03

    Cylinder Unit

    Sludge is instantly thickened in the thickening zone of the cylinder, and then the inner pressure increased at the dewatering zone helps sludge being dewatered well.
  4. 04

    Discharge Outlet for Dewatered Cake

    Further pressure is applied from the outlet side with the end plate, discharging dewatered cake with 20% (+/-5%) dry solids content.

CASE STUDIES / TESTIMONIALS

List of Case Studies

RENTAL

Rental of Sludge Dewatering Presses

You may wonder, “Can the machine dewater the sludge as desired?” or “Is it difficult to operate the machine?”
In addition to eliminating concerns before purchase, you can also use our products as a replacement machine during the service period of an existing dewatering machine or during the construction period of a wastewater treatment facility.

Flow for Product Installation

流れ
Feel free to contact us. After collecting information about your treatment process, sludge volume, operating hours, and other conditions, we will select the most suitable model for your sludge and your concerns. During jar test, we will simulate the amount of chemicals to be dosed, the estimated water content of the dewatered cake, etc. Upon request, a pilot test can be performed at your wastewater treatment plant (for a fee). After determining the specifications and ancillary equipment, we will start producing the equipment. Our sales representative or service engineer will perform operational adjustments at your wastewater treatment plant and you will check how to operate the system before we hand over the equipment.
