Polymer HYBRID V series

Polymer Hybrid V has great flocculation efficiency. They are suitable for various types of wastewater treatment systems, such as sludge dewatering presses, dissolved-air floatation (DAF) systems, and chemical precipitation systems. Hybrid V has anionic, cationic, non-ionic and zwitterionic coagulants. The coagulants also come in two different forms: emulsion and powder. Polymer Make-up System AF/DG/AP Series and Polymore will automate the whole process, including measurement of a polymer stock solution and dilution water and agitation. Hybrid V is officially recommended for our sludge dewatering presses and thickeners.

Comparison between emulsion and powder

Polymer with 40% effective concentration
Priced more competitively than emulsion coagulants
  Polymer Coagulants Hybrid V Series Emulsion Polymer Coagulants Hybrid V Series Powder
Dissolution time 1-10 minutes 1 hour
Dilution ratio 1:200 to 1:800
(The standard ratio is 1:400.)
1:500 to 1:2000
(The standard ratio is 1:1000.)
Packing 10 kg/box or 1-ton container 10 kg/bag or 15 kg/bag

Why we recommend emulsion coagulants

Great solubility

Emulsion coagulants are much more soluble than powder coagulants. The polymer portion of a powder coagulant needs to be hydrated before it dissolves. It usually takes more than an hour for the mixture to be stabilized. The emulsion dissolves in about one quarter of the time required for the powder. It will be ready for use in a short time. Also, unlike powder, emulsion hardly forms lumps and produces a uniform coagulant without waste.

Hygienic handling

Emulsion coagulants are also highly hygienic in handling. Unlike powder coagulants, emulsion coagulants do not fly in the air and there is no danger of inhalation.

Select Product Lineup

Type Product Code Primary Component Ionicity Effective pH
Emulsion HB-6055 Polyacrylamide Medium anion 5 to 12
HB-6080 Polyacrylamide Strong anion 3 to 10
HB-7100 Polyacrylic acid ester Cation 3 to 10
HB-7175 Polyacrylic acid ester Cation 3 to 10
HB-8042 Polyacrylic acid ester Zwitter ion 3 to 10
HB-8045 Polyacrylic acid ester Zwitter ion 3 to 10
Powder HF-6520 Polyacrylamide Weak anion 6 to 12
HF-7510 Polyacrylic acid ester Strong cation 3 to 10
HF-8530 Polyacrylic acid ester Zwitter ion 3 to 10

*Various other products are available. Please contact us for more detailed information.

Strong ally of wastewater treatment W series
(Bulking Inhibitors, Sludge Modifiers, Nutrients, Microorganism Agents, Deodorizing Agents, Treatment Agent for Oil-Containing Effluent)

  • Having high load wastewater or commingling of inhibitor
  • Arising settlement difficulty by filamentous-bulking, foaming and scum formation by actinomycetes
  • Arising sludge carry-over by over loading of inflow quantity
  • No idea of the reason for declining quality of treated water

Aren’t you having these problems with your wastewater treatment?
Hybrid W series have a wide range of chemicals from Splitting Agents for Fats and Oils to Deodorizing Agents for sludge cake, solve various problems coming up in the process of wastewater treatment.

Product Lineup

Purpose Product Name Feature
Bulking Inhibitors BY10 Sedimentation Promoter
BY20 Sedimentation Promoter、Elimination of Actinomycetes
BY30 Standard Product of Bulking Inhibitor
BY40 Inflict great damage with light addition
BY50 Dissolution of Scum, Defoaming Agent
Sludge Modifiers SK100 Used as seeding agents for newly constructed microorganism treatment tanks
SK101 Standard product of highly-activated microorganism agent
SK103 Activation promoter dispensed natural chemical for microorganism treatment tank
Nutrients NZ201 Activation of microorganisms by a infinitesimal amount of nutrient
NZ202 Activation of microorganisms by natural activator
Microorganism Agents BS300 Activated sludge stabilizes by continuously-additioned sludge-digestion promoter
BS302 Sludge-digestion promotion, Splitting of fats and oils
Deodorizing Agents SZ100 Immediate deodorizing of hydrogen sulfide and mercaptans
SZ101 Deodorizing and antibacterial of various malodors by natural plant extract
Treatment Agent for Oil-Containing Effluent FS1 Solubilizing of oil contained in effluent in a short time and promoting of biodegradation
Functional Agents KY1 Removal of pectic substances

Inorganic Coagulants

There are also inorganic coagulants that can be used in all wastewater treatment processes such as sludge dewatering, dissolved-air flotation and chemically precipitation.

Polyferric Sulfate

Polyferric Sulfate

PAC (Polyaluminum Chloride)

PAC (Polyaluminum Chloride)


Polymer Make-up System AF/AP Series, Polymore

Poly Make-up System
AF/DG/AP Series, and Polymore

For labor saving in sludge treatment
